TELEWAVE INC ANT450D Antena de Dipolo 406-512 MHz Ganancia u
ANT450D Antena de Dipolo 406-512 MHz Ganancia unitaria.
Enviamos a todo Mexico. Favor de solicitar su cotizacion por Telefono.
Tambien puede recoger su pedido en nuestras oficinas fisicas. Consultar direccion de oficinas Trumon.
ANT450D Antena de Dipolo, 406-512 MHz Ganancia unitaria. ANT-450D
Características
- The Telewave ANT450D series consists of single dual and 4-element dipole array antennas with a precision phasing harness for optimum performance.
- The antenna horizontal pattern is field adjustable for any current or future coverage requirements.
- The wide bandwidth and high efficiency of these antennas make them ideal for many applications including trunking business public safety government and amateur radio.
Especificaciones
- Specific Frequency: 406-512 MHz
- Antenna Pattern: Adjustable
- Gain dBd: 1 dBd / 2.5 dBd
- Gain dBi: 3.1 dBi / 4.6 dBi
- Polarization: Vertical
- Vertical Beamwidth: 71 deg
- Horizontal Beamwidth: 66 deg
- Maximum VSWR: 1.5:1
- Maximum Power: 500 W
- Lightning Protection: DC Ground
- RF Connectors: N Male
- Connector: Placement Pigtail
- Jumper Included: Yes
- Type of Hardware Included: Clamp set for 1.5-2.5 OD
- Maximum Rated: Wind Velocity 175 mile/h
- Item Height: 13 in
- Item Length: 12 in
- Item Weight: 6 lb
*Pregunte por tiempo de entrega.
ANT-450D Antena de Dipolo, 406-512 MHz Ganancia unitaria. ANT450D
